This slip ring with separate silver rotor and PCB stator is specifically designed for precision applications such as robotic arms, servo worktables, and automated equipment. It features 11 channels and flexible size options, supporting multi-circuit connections while ensuring reliable signal and power transmission. With its separate contacts, it can be installed more quickly into rotating systems with limited space or complex structures.
Drawing(mm)
Parameters
Mechanical:
|
Working speed |
300rpm |
|
Operating temperature |
-40℃~ +100℃ |
|
Contact material |
Gold to gold |
Electrical:
|
Circuit |
≤18 |
|
Current |
2A |
|
Voltage |
≤380VAC |
|
Dielectric strength |
≥500V@50Hz between each circuit |
|
Insulation resistance |
500MΩ@ 500VDC |
|
Electric noise |
≤7mΩ |
|
Lead wire size |
28AWG, ,UL, color Teflon, silver or tin plated |
|
Lead wire length |
200mm |
|
Life-span |
80,000,000rounds |
Application
The slip ring with separate silver rotor and PCB stator is used in various industries, such as:
Wind Turbines
Industrial Machinery
Medical Equipment
Test and Measurement
Amusement Rides
Defense Applications
